140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube
140pcs Box/146pcs Opp Heat Shrink Tube

140pcs Box/146pcs Opp Heat Shrink Tube

Regular price $33.98 Sale price $16.99
Unit price  per



Description:

Big collection of heat shrink tubing,8 Specifications,5 colors
Supplied Internal Diameter: 1.0mm, 2.0mm, 3.0mm, 4.0mm,6.0mm, 8.0mm, 10.0mm, 14.0mm
Color: Black,Red,Yellow,Blue,Green
Material: Polyolefin
Shrinkage Ratio: 2:1 (will maximum shrink to 1/2 its supplied diameter)
Operating Temperature: -55°C to +125°C
Minimum Shrinkage Temp: +70°C
Full Shrinkage Temp: +110°C Maximum
Tensile Strength: 10.4 Mpa
Dielectric Strength:15 kV/mm
Flammability: Flame Retardant

Usage Method
Select the proper size connector for the wires, stripped wires.
Insert the stripped wires into the connector.
Apply heat evenly to the connector from the 2 ends first until tubing shrinks and the adhesive flows, then continuously apply heat evenly until solder sleeve melt and seal.


Specifications
Package Include
Type 1 - 140pcs Box
(Quantity x Supplied internal diameter x Single length)
50pcs x 2.0 x 30mm (Yellow,Black,Red,Green)
25pcs x 3.0 x 65mm (Yellow,Black,Red,Blue)
15pcs x 4.0 x 65mm (Yellow,Black,Red,Green)
10pcs x 5.0 x 65mm (Yellow,Black,Red,Blue)
10pcs x 6.0 x 65mm (Yellow,Black,Red,Green)
15pcs x 8.0 x 90mm (Yellow,Black,Red,Blue)
15pcs x 10.0 x 90mm (Yellow,Black,Red,Green)

Type 2 - 164pcs Opp

(Quantity x Supplied internal diameter x Single length)
60pcs x 1.0 x 40mm (Yellow,Black,Red,Green)
30pcs x 2.0 x 40mm (Yellow,Black,Red,Blue)
20pcs x 3.0 x 40mm (Yellow,Black,Red,Green)
16pcs x 4.0 x 40mm (Yellow,Black,Red,Blue)
12pcs x 6.0 x 40mm (Yellow,Black,Red,Green)
10pcs x 8.0 x 80mm (Yellow,Black,Red,Blue)
8pcs x 10.0 x 80mm (Yellow,Black,Red,Green)
8pcs x 14.0 x 80mm (Yellow,Black,Red,Blue)
